产品详情:
Vehicle parameters |
|||
Vehicle Model |
HLW5042ZLJB |
Vehicle Brand |
HLW |
Overall dimensions |
4985X1720X2080mm |
Curb weight |
2575kg |
Garbage container dimensions |
2800X1650X800mm |
Garbage container volume |
3.0m3 |
Chassis parameters |
|||||
Chassis model |
BJ1042V9JA2 |
Chassis brand |
FOTON |
||
Overall dimensions |
4985x1690x2080mm |
Wheel base |
2600mm |
||
Front/rear wheel track |
1345/1240mm |
Front/rear suspension |
1115/1270mm |
||
Approach/departure angle |
18/20° |
Maximum speed |
95km/h |
||
Chassis Manufacturer |
BEIQI FOTON MOTOR CO.,LTD |
||||
Cab |
Configuration |
1560 single row cab,allowable 2 passengers,with warm air. |
|||
Color |
White,other color is optional |
||||
Engine |
Model |
QC480ZLQ |
|||
Emission |
Euro 1 |
||||
Type |
4 cylinders,in-line,turbo charger,diesel engine |
||||
Rated power |
62hp |
||||
Displacement |
1809ml |
||||
Bore x stroke |
80x90mm |
||||
Manufacturer |
Anhui Quan Chai Power Co., Ltd |
||||
Tire |
Size |
6.00-13 nylon tire |
|||
Number |
6+1 nos |
||||
Fuel tank |
70L iron oil tank |
||||
Rear axle |
3.0 tons |
||||
Drive form |
4X2 |
||||
Rated voltage |
Camel brand,24V,DC |
||||
Transmissions |
5 speed forward 1 reverse |
||||
Steering device |
Steering wheel |
||||
Steering wheel |
Left hand drive |
||||
Selective configuration |
Steel wire tire,air conditioner |
||||
If there is a slight change in the chassis parameters above,please take the actual product as the standard |
Upper structure parameters |
||||
Garbage container dimensions |
2800X1650X800mm |
Garbage container volume |
3.0m3 |
|
Garbage container material |
Carbon steel |
Side wall |
2.5mm |
|
Bottom plate |
3mm |
Color and Logo |
Optional |
|
Standard configuration |
Chassis,master cylinder,one garbage container. |
