Product name: HLW5141XFBE Blasting Material Transport Truck

Category: Blasting Material Transport Truck

Brand DONGFENG

Loading capacity 10000KG

Engine 190hp

Van size 6500x2400x2000mm

Product introduction:


Vehicle parameters

Vehicle Model

HLW5141XFBE

Vehicle Brand

FOMON

Overall dimensions

8600X2500X3400mm

Curb weight

5100kg

Van dimensions

6500X2400X2000mm

Loading capacity

15000kg



Chassis parameters

Chassis model

EQ1141KJ

Chassis brand

DONGFENG

Overall dimensions

7600x2462x2710mm

Wheel base

4500mm

Front/rear wheel track

1940x1860mm

Front/rear suspension

1205/1895mm

Approach/departure angle

25/18°

Maximum speed

90km/h

Chassis Manufacturer

Dongfeng Motor Company

Cab

Configuration

A row and a half deluxe cab(with sleeping berth),allowable 3 passengers

Color

Blue,other color is optional

Engine

Model

B190 33

Emission

Euro 3

Type

6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling,diesel engine

Rated power

190hp,rated power speed 2500rpm

Displacement

5900ml

Max.torque

640N.m

Bore x stroke

102x120mm

Manufacturer

Dongfeng Cummins Engine Co., Ltd.

Tire

Size

10.00-20-16 nylon tire

Number

6+1 nos

Frame

(250×80×7)mm,parts are double layers.

Fuel tank

160L,steel

Front axle

5.0T

Rear axle

10.0T

Drive form

4X2

Rated voltage

24V,DC

Transmissions

Gearbox 8JS85E, 8 speed forward 1 reverse.

Steering device

Power assisted steering

Steering wheel

Left hand drive

If there is a slight change in the chassis parameters above,please take the actual product as the standard





Van body structure parameters                                                                 www.hltq.com

Van dimensions

6500X2400X2000mm

Loading capacity

15000kg

Outer van material

Cold rolled steel sheet

Inter van material

Aluminium alloy

Flame retardant layer

5CM Polyurethane foam





Color and Logo

Optional




Standard configuration

Outer van material Cold rolled steel sheet,Inter van material Aluminium alloy,Flame retardant layer 5CM Polyurethane foam.Van size 6500x2400x2000mm.Fixed carriage sleeping ring, anti-fire smoke alarm, anti-theft alarm installed on the door, front anti-collision anti-static rubber. The bottom is anti-static rubber pad on explosion-proof steel plate.



Sales Manager: Mr Zuo Chen

E-mail: market@hltq.com

Mobile Phone: +86 183 0722 6508

Whatsapp and Wechat: +86 183 0722 6508
