BJ2037Y3MDV-AB Pickup

Vehicle parameters

Vehicle Model

BJ2037Y3MDV-AB

Vehicle Brand

FOTON

Overall dimensions

5310X1860X1860mm

Curb weight

1930kg

Van dimensions

1520X1580X440mm

Loading capacity

1500kg

Chassis parameters

Chassis model

BJ2037Y3MDV-AB

Chassis brand

FOTON

Overall dimensions

5310X1860X1860mm

Wheel base

3105mm

Front/rear wheel track

1439/1446mm

Front/rear suspension

850/917mm

Approach/departure angle

32/25°

Maximum speed

130km/h

Chassis Manufacturer

Beiqi Foton Motor Co., Ltd

Cab

Configuration

Double row ,allowable 2 +3 passengers, air conditioner (Cooling and heating mixing type electric air conditioner), Air heater, 2 speakers, AM/FM radio + audio input port (AUX + USB)+ CD Player, Cigar lighter,

Color

Blue, other color is optional

Engine

Model

4JB1

Emission

Euro 2

Rated power

115hp

Max.torque

280N.m

Manufacturer

Beiqi Foton Motor Co., Ltd.

Tire

Size

245/70R16

Number

4+1 nos

Drive form

4X4

Body

Front bumper- Black front grille model, Rear bumper- U-shape bumper, Guardrail of the cargo, Wheel arch, Side pedal, External packing of the vehicle body,

Inner

First-row seat Woven velvet seat cover, manual, 2-way headrest  with abdominal support, Second-row seat Leather + fixed backrest+ upturning cushion, Carpet

Suspension

Multi leaf springs

Rated voltage

24V,DC

Transmissions

TC038 , 5speed 1 forwarder.

Steering device

Power assisted steering

Steering wheel

Left hand drive

Selective configuration

If there is a slight change in the chassis parameters above, please take the actual product as the standard

Van body structure parameters

Van dimensions

1520X1580X440mm

Loading capacity

1500kg

Van material

Corrugated iron tile

Color and Logo

Optional

Standard configuration

Chassis, sub frame, corrugated iron tile van body, side step, rear bumper
