HLW5061XXYB van truck

Vehicle parameters

Vehicle Model

HLW5061XXYB

Vehicle Brand

HLW

Overall dimensions

6900X2250X3200mm

Curb weight

4700kg

Van dimensions

4700X2050X1800mm

Loading capacity

7tons

Chassis parameters

Chassis model

BJ1061VCJEA-F1

Chassis brand

FOTON

Overall dimensions

6725X2100X2280mm

Wheel base

3800mm

Front/rear wheel track

1530/1485mm

Front/rear suspension

1085/1175mm

Approach/departure angle

18/17°

Maximum speed

110km/h

Chassis Manufacturer

BEIQI FOTON MOTOR CO.,LTD

Cab

Configuration

A1995 sing row cab, allowable 2 passengers, with warm air, wind breaker.

Color

White, other color is optional

Engine

Model

ISF3.8s4R154

Emission

Euro 4

Type

in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Rated power

154hp,rated power speed 2600rpm

Displacement

3760ml

Max.torque

500N.m

Bore&Stroke

102X115mm

Manufacturer

Beiqi Futian Cummins Engine Co., Limited

Tire

Size

235/75R17.5 tubeless tire

Number

6+1 nos

Front axle

2.5tons

Rear axle

6.0tons

Drive form

4X2

Rated voltage

24V,DC

Transmissions

6 speed forward 1 reverse

Steering device

Power assisted steering

Steering wheel

Left hand drive

If there is a slight change in the chassis parameters above,please take the actual product as the standard

Van body structure parameters

Van dimensions

4700X2050X1800mm

Loading capacity

7tons

Van material

Corrugated iron tile

Side door

Two side doors

Color and Logo

Optional

Standard configuration

Chassis,sub frame,corrugated iron tile van body.
