HLW5080XXYQ5 van truck 700P

Vehicle parameters

Vehicle Model

HLW5080XXYQ5

Curb weight

4560kg

Overall dimensions

8955X2396X3350mm

Loading capacity

10tons

Chassis parameters

Chassis model

QL1080A8PAY

Chassis brand

ISUZU

Overall dimensions

8912X2170X2410mm

Wheel base

5200mm

Front/rear wheel track

1680/1650mm

Front/rear suspension

1110/2602mm

Approach/departure angle

17/11°

Maximum speed

110km/h

Chassis Manufacturer

QingLing Motors (Group) Co., Ltd.

Cab

Configuration

700P,single row cab,allowable 3 passengers,air conditioner, USB radio interface,cab can be flipped.

Color

White,other color is optional

Engine

Model

4HK1-TC51

Emission

Euro 5

Type

4 cylinders, 4 valve,4-stroke,in-line,common rail,diesel engine,oil brake.

Rated power

191hp

Displacement

5193ml

Manufacturer

Isuzu (ChongQing) Engine Co., Ltd.

Tire

Size

Factory standard tire

Number

6+1 nos

Front axle

4.0tons

Rear axle

7.0 tons

Drive form

4X2

Rated voltage

24V,DC

Transmissions

6 speed forward 1 reverse.

Steering device

Power assisted steering

Steering wheel

Left hand drive

If there is a slight change in the chassis parameters above,please take the actual product as the standard

Van body structure parameters

Van dimensions

7000X2170X1800mm

Loading capacity

8-10tons

Van material

Corrugated iron tile

Side door

Double doors on the right hand side

Color and Logo

Optional

Standard configuration

Chassis,sub frame,corrugated iron tile van body.
