Product introduction:
Vehicle parameters |
|||
Vehicle Model |
HLW50403EQ |
Curb weight |
1680kg |
Overall dimensions |
4870X1764X2200mm |
Loading capacity |
2500kg |
Chassis parameters |
|||||
Chassis model |
QL10403EARY |
Chassis brand |
ISUZU |
||
Overall dimensions |
4605X1695X2105mm |
Wheel base |
2490mm |
||
Front/rear wheel track |
1385/1395mm |
Front/rear suspension |
1015/1100mm |
||
Approach/departure angle |
24/20° |
Maximum speed |
98km/h |
||
Chassis Manufacturer |
QingLing Motors (Group) Co., Ltd |
||||
Cab |
Configuration |
100P, single row cab, allowable 2 passengers, air conditioner, USB radio interface. |
|||
Color |
White, other color is optional |
||||
Engine |
Model |
4JB1CN |
|||
Emission |
Euro 4 |
||||
Type |
4 cylinders, in-line, diesel engine |
||||
Rated power |
98hp |
||||
Displacement |
2771ml |
||||
Manufacturer |
Isuzu (ChongQing) Engine Co., LTD |
||||
Tire |
Size |
7.00-15 nylon tire |
|||
Number |
4+1 nos |
||||
Frame |
172X65(4)mm |
||||
Front axle |
2.5 tons |
||||
Rear axle |
3.0 tons |
||||
Drive form |
4X2 |
||||
Rated voltage |
24V,DC |
||||
Transmissions |
Isuzu MSB five speed transmission,5 speed forward 1 reverse. |
||||
Steering device |
Power assisted steering |
||||
Steering wheel |
Left hand drive |
||||
Selective configuration |
|
||||
If there is a slight change in the chassis parameters above,please take the actual product as the standard |
Cargo body structure parameters |
||||
Cargo dimensions |
3045X1600X360mm |
Loading capacity |
2500kg |
|
Cargo material |
Corrugated iron tile |
Color and Logo |
Optional |
|
Standard configuration |
Chassis,sub frame,corrugated iron tile cargo body. |
