HLW50403Q cargo truck

Vehicle parameters

Vehicle Model

HLW50403Q

Vehicle Brand

HLW

Overall dimensions

5900X1880X2240mm

Curb weight

2850kg

Van dimensions

3185X1790X400mm

Loading capacity

5000kg

Chassis parameters

Chassis model

QL10403HWRY

Chassis brand

ISUZU

Overall dimensions

5850x1880x2220mm

Wheel base

3360mm

Front/rear wheel track

1504/1425mm

Front/rear suspension

1015/1525mm

Approach/departure angle

24/16°

Maximum speed

95km/h

Chassis Manufacturer

QingLing Motors (Group) Co., Ltd.

Cab

Configuration

100P, double row cab, allowable 2+3 passengers,air conditioner, USB radio interface, with oil brake vacuum booster pump.

Color

White,other color is optional

Engine

Model

4JB1CN

Emission

Euro 4

Type

4 cylinders, in-line, 4-stroke,diesel engine

Rated power

98hp

Displacement

2771ml

Manufacturer

Isuzu Engine (Chongqing) Co., Ltd.

Tire

Size

7.00-15 10PR nylon tire

Number

6+1 nos

Frame

172X65(4)mm

Front axle

2-2.5 tons

Rear axle

3-4.8 tons

Drive form

4X2

Suspension

Multi leaf springs

Rated voltage

24V,DC

Transmissions

Isuzu MSB five speed transmission, 5 speed forward 1 reverse.

Steering device

Power assisted steering

Steering wheel

Left hand drive

If there is a slight change in the chassis parameters above,please take the actual product as the standard

Upper structure parameters

Van dimensions

3185X1790X380mm

Loading capacity

5TONS

Van material

Corrugated iron tile

Color and Logo

Optional

Standard configuration

Chassis,sub frame,corrugated iron tile van body.
